Fire Rated Glass

FireLite® is a 3/16″ (5 mm) thick fire-rated glazing material. It is listed for use in non-impact safety-rated locations such as transoms and borrowed lites with fire rating requirements ranging from 20 to 90 minutes. Trusted for over 20 years, the FireLite family of products now feature ultraHD® Technology for superior color and surface quality.

• Now with ultraHD® Technology for improved color, clarity and surface quality
• Fire-rated for up to 90 minutes with required hose stream test
• Glass ceramic
• Clear and wireless
• Available in two surface conditions for clear viewing, Premium Grade and Standard Grade
• Also available in an obscure pattern
• Large sizes available
• Withstands thermal shock

FireLite Plus® is a nominal 5/16″ (8 mm) thick laminated fire-rated and impact safety-rated glazing material. It is listed for use in doors, sidelites, transoms and borrowed lites with fire rating requirements ranging from 20 minutes to 3 hours. Trusted for over 20 years, the FireLite family of products now feature ultraHD® Technology for superior color and surface quality

Now with ultraHD® Technology for improved color, clarity and surface quality

Fire-rated for up to 3 hours with required hose stream test

Impact Safety Rated – ANSI Z97.1 and CPSC 16CFR1201 (Cat. I and II)

Glass ceramic

Clear and wireless

Withstands thermal shock

Protects from fire and impact on both sides of the glass

Available in two surface conditions for clear viewing, Premium Grade and Standard Grade

Large sizes available

May be lightly sandblasted/etched on one side without affecting fire rating

FireLite® NT is a 3/16″ (5 mm) thick fire-rated and impact safety-rated glazing material, composed of FireLite and surface-applied fire-rated film. It is listed for use in doors, sidelites, transoms and borrowed lites with fire rating requirements ranging from 20 minutes to 3 hours. Trusted for over 20 years, the FireLite family of products now feature ultraHD® Technology for superior color and surface quality

• Now with ultraHD® Technology for improved color, clarity and surface quality
• Fire-rated for up to 3 hours with required hose stream test
• Impact Safety Rated – ANSI Z97.1 and CPSC 16CFR1201 (Cat. I and II)
• Glass ceramic
• Clear and wireless
• Withstands thermal shock
• Protects from fire and impact on both sides of the glass
• Available in two surface conditions for clear viewing, Premium Grade and Standard Grade
• Large sizes available
• May be lightly sandblasted/etched on one side without affecting fire rating

Pilkington Pyrostop® is a fire-rated and impact safety-rated glazing material. Pilkington Pyrostop also blocks radiant heat, protecting people and valuables on the non-fire side of the glass where radiant heat transfer might be a concern. It is listed for use in doors, sidelites, transoms, borrowed lites and wall applications with a fire rating of up to 2 hours

• Protection against radiant and conductive heat transfer
• Barrier to fire and smoke
• Fire-rated for up to 2 hours with required hose stream test
• Impact safety-rated – meets ANSI Z97.1 and CPSC 16CFR1201 (Cat. I and II)
• Wireless with nearly the same clarity as ordinary float glass
• For use in interior and/or exterior applications
• May be lightly sandblasted or etched on one side without affecting fire rating.
• Available in insulated units with other glass products including (but not limited to): Tinted, Low-E, One-way Mirror, Reflective, Art Glass, Security Glass
• Available with Level III Bullet Resistance Rated
• Multi-laminate, not a sensitive polymer gel unit

Fireglass®20 is a 1/4″ (6 mm) thick fire-rated and impact safety-rated glazing material. It is listed for use in doors with a fire rating requirement of 20 minutes

• Fire-rated for 20 minutes
• Impact Safety Rated – ANSI Z97.1 and CPSC 16CFR1201 (Cat. I and II)
• Tempered (at least 4 times stronger than wired glass)
• Clear and wireless
• Fits in Fireframes® Designer Series frames from TGP, or standard fire-rated frames
• Large sizes available
• Passes positive pressure test standards UL 10C
• May be lightly sandblasted/etched on one side without affecting fire rating
• For use in interior and exterior applications
• Manufactured in U.S.A.
• Available in insulated glass units (IGU) with other glass products, including (but not limited to):Tinted, Low-E, Art Glass, Reflective, One-way mirror

WireLite® NT is a 1/4″ (6 mm) glazing material composed of wired glass and a fire-rated surface-applied film. WireLite NT is listed for use in doors, sidelites, transoms and borrowed lites.

• Fire-rated for 20-90 minutes with required hose stream test
• Impact safety-rated-meets ANSI Z97.1 and CPSC 16CFR1201 (Cat. I and Cat. II)
• Wired glass with high performance surface-applied fire-rated film
• Available in Diamond Clear (3/4″ pattern) and Georgian Clear (1/2″ pattern)
• Available as an insulated glass unit (IGU)
• Withstands thermal shock
